Connecting 3rd party iPad applications
print icon
TJ Sutton
Feb 06, 2019
views icon 2299

Connecting 3rd party iPad applications



https://desk.zoho.com/DocsDisplay?zgId=58375072&mode=inline&blockId=akrkj031df90aa040489082242c95af5e3f49

https://desk.zoho.com/DocsDisplay?zgId=58375072&mode=inline&blockId=akrkj2ba2eb2ca7cf47259b837ceeb694ec51



https://desk.zoho.com/DocsDisplay?zgId=58375072&mode=inline&blockId=akrkj9a7302d6eea7470d8f691e2d1ff8c27b



https://desk.zoho.com/DocsDisplay?zgId=58375072&mode=inline&blockId=akrkj0cef1a56978d48cbaebd46528f537dfd

https://desk.zoho.com/DocsDisplay?zgId=58375072&mode=inline&blockId=akrkj3caa31b784d1463797edd82b42d129d4

https://desk.zoho.com/DocsDisplay?zgId=58375072&mode=inline&blockId=akrkj67ac8a10e1b14c65a235eb0fd839c885

https://desk.zoho.com/DocsDisplay?zgId=58375072&mode=inline&blockId=akrkjb130efac1cff487fbb2d2ce70cb065aa

https://desk.zoho.com/DocsDisplay?zgId=58375072&mode=inline&blockId=akrkj1121983e53b545b99148ada98a7824f8


Following the above procedure, power off the IFD, then power the system back on to boot into normal "flight" mode.  You should be able to now connect your Ipad to the "Stratus" network, and feed flight plan information to the IFD.
